Linear Bar Grille - Removable Core

DESCRIPTION:

• Frame and face bars are of high quality extruded aluminium profiled construction with the advantages of corrosion resistance and rigidity.
• Horizontal face bars with 0°, 15°-1 way throw and 15°-2 way throw, 30° or 45° are fixed rigidly to the frame with round aluminium pipes.
• The blades are rigidly fixed together by means of 6mm pipe. The core can be removed for accessibility behind the grille, and can be fixed back with push fit mechanism.
• Total structure is manufactured by mechanical assembly, assuring rigidity and to maintain straight line appearance.
• The frame is constructed with 45° corners and mechanically reinforced with corner cleats for rigidity and aesthetics.
